Merida Eone-Forty 4000 Full-Suspension Mountain Bike

Description

eONE-FORTY CFA FRAME

Carbon front triangle with integrated battery technology, paired with 6016 rear end with aggressive enduro/trail geometry and 133 mm rear wheel travel – Shimano STePS E8000/E7000 motors allow for short chain stays delivering agility. Internal cable guide for rattle free running. Full carbon motor bracket creates an integrated appearance of the motor into the frame as well as provides an extremely strong connection between frame and motor.

FRAME eONE-FORTY CFA

• material: carbon
• 133mm suspension travel
• 29/27.5″ wheelsize
• 148x12mm axle standard
• intube
• max. 504 Wh

FRAME SIZE S, M, L, XL, XXLCOLOR GLOSSY SPARKLING RED/MATT BLACKFORK Suntour RAIDON34 LOR

• Air
• 140mm suspension travel
• Tapered
• 51mm fork offset

SHOCK SUNTOUR RS EDGE TR LOR8

• lockout

BRAKES Shimano MT-420 / Shimano MT-400

• 4 piston
• 2 piston

ROTORS Shimano RT30 / Shimano RTEM300

• 203 mm
• 180 mm

HEADSET MERIDA 1901HANDLEBAR MERIDA Expert eTR

• material: aluminium
• 780mm width
• 20mm rise

HANDLEBAR STEM MERIDA Expert eTR

• material: aluminium
• 35mm diameter
• 0° stem angle
• 50 mm all sizes

GRIP MERIDA Expert ECDERAILLEUR (R) Shimano Deore Shadow+SHIFTERS Shimano DeoreSEAT POST MERIDA COMP TR

• 30.9mm diameter
• 0mm setback
• S 100mm travel seatpost – M/L/XL/XXL 125mm travel seatpost

SEAT CLAMP MERIDA Expert clampSADDLE MERIDA Comp CC

• V-mount

PEDAL VP

• VPE-537

CHAIN KMC e10SCHAINWHEEL Shimano CRE70-B

• 34 teeth
• Shimano FC-E8000

CRANK Shimano FC-E8000

• 165 mm all sizes

FREEWHEEL Shimano HG500

• 11-42 teeth
• 10 speed

BOTTOM BRAKET includedHUBS Shimano MT400-B

• 110x15mm width front hub
• 32 spoke holes
• Centerlock
• 148x12mm width rear hub
• 36 spoke holes
• Centerlock

RIM MERIDA COMP TR

• 29mm inner width
• material: aluminium

TYRE FRONT Maxxis DHF

• 29×2.5 “
• fold
• EXO TR Dual compound

TYRE REAR Maxxis DHR II

• 27.5×2.6 “
• fold
• EXO TR Dual compound

AXLES MERIDA COMP TR

• including removeable lever, 6/4mm allen key

SPOKES Black stainlessLIGHT FRONT CG-119PG-BLACK(1)LIGHT REAR CG-404RG-BLKDRIVE UNIT Shimano E7000

• 60Nm

BATTERY Shimano E8035

• 504Wh

BATTERY LOCK ABUS lock for Shimano integrated battery, no key use allen keyBATTERY CHARGER Shimano EC-E6002

• 2A

DISPLAY w/o displayWEIGHT 22.43 kg

weighed at frame size M without pedals
