Description

THE ALL-NEW TRAIL WIDE IS YOUR GO-TO WHEELSET NO MATTER THE CONDITIONS. OPTIMISED TO STILL TAKE THE A-LINES ON THE DESCENTS AND NOT HOLD YOU BACK ON THE CLIMBS.

27.5/29″ | 30mm Wide Int. | 520g

The Trail Wide V2 rim includes details which are high on the durability factor to make sure you finish every ride or stage. The 6069-T6 (490 MPa, +69% tensile strength vs 6061-T6) welded rim sticks, with the wider-is-better mantra with an internal 30mm rim width. Optimized for 2.35″-2.6″ tyres, the Trail Wide V2 rim provides support to the tyre during hard cornering or hucking off that step-down you’ve been eying off for a few months!

Detailed Specifications

Rim

• Tubeless-ready – designed to work excellently with tubeless tyres. Tubeless rim tape offered separately.
• 6069 T6 (490 MPa, + 69% Ultimate Tensile Strength over 6061-T6) welded construction
• H-lock bead-seat up-kicks for easy and secure tubeless installation
• 30mm internal width ideal for 2.35″-2.6″ tyre widths, but also work very well with 2.3″-2.8″
• Matt black work-hardened shot-peened finish with laser etched graphics for superior durability.
• Maximum tyre pressure for this rim: up to 2.5″ do not exceed 40psi. 2.6 – 2.8″ – do not exceed 30psi. Please do not exceed the maximum pressure stated on your tyre.
• ERD: 600.55mm
• Lacing: Cross 3
• Recommended Spoke Tension: 105~120kgf
• Weight: 520g
